Product Overview: The ATX U43W2PGA3A3 features dual push buttons accompanied by a green pilot light, offering intuitive control and status indication in hazardous areas. Engineered for Zones 1, 2, 21, and 22,…
Product Overview:
The ATX U43W2PGA3A3 features dual push buttons accompanied by a green pilot light, offering intuitive control and status indication in hazardous areas. Engineered for Zones 1, 2, 21, and 22, it upholds safety and reliability.
ATX U43W2PGA3A3 Key Features:
Pilot Light: Green indicator for system status.
Push Buttons:
Green ‘I’ button with 1NO + 1NC contacts.
Red ‘O’ button with 1NO + 1NC contacts.
Enclosure: IP66-rated; IK09 impact resistance.
Cable Entries: 2 x M20 bottom entries.
Dimensions & Weight: Volume of 2.5 dm³; weighs 0.78 kg.
Certifications:
ATEX: II 2 GD
Explosion Protection: Ex de IIC / Ex demb IIC / Ex tD A21
| Category | ATEX Control Stations |
|---|
