Andel Floodline Breeameter water leak detection system monitors flow in line with Wat 02 and Wat 03 to the mains water supply to premises.
Andel Floodline Breeameter water leak detection system monitors flow in line with Wat 02 and Wat 03 to the mains water supply to premises.
One flow meter is positioned next to the site boundary and the other near the stop cock. The system is able to monitor and quickly identify any excessive water usage between the two flow meters.
Output relays are provided for “mains power failure”, “flow alarm”, flow meter fault” and “complete power failure”
Contact our team to discuss how leak detection control panels, sensors and cables can secure BREEAM credits for sustainable building ratings.
Function: Water leak detection or excessive water use
Power Supply: 110/230 VAC 50/60Hz mains operated 51Watts (max)
Dimensions: H400 x W300 x D150 mm
Monitoring:
External – Pipework
LEAK – continuous monitoring
FLOW METER FAULT – continuous monitoring
Alarm Indicators:
The system uses a 4 x 12 LCD backlit display which displays real text messages in order of priority of Alarm/Message.
Audible buzzer alarm
All alarms displayed continuously until corrected and reset on the system
Outputs:
1. Mains Fail – SPCO Relay (5A @ 250VAC)
2. Flow Alarm – SPCO (5A @ 250VAC)
3. Flow Meter Fault – SPCO (5A @ 250VAC)
4. Complete Power Failure – SPCO (5A @ 250VAC)
All relays are “clean” volt-free contacts.
Read our Blog to understand how the specification and installation of BREEAM Wat 03 Leak Detection Systems can help achieve BREEAM credits.
| Brand | Andel |
|---|---|
| Category | Mechanical |
