Crowcon Xsafe | Gas Detection for Non-Hazardous Areas
The Crowcon Xsafe fixed gas detector is a robust flammable gas detector suitable for use in non-hazardous areas.
Part of the Xgard family of gas detection equipment, the Xsafe gas detector has a tough alloy housing, offers a standard design and reliability without the extra cost of certified electronics.
Crowcon Xsafe gas detector is a non-certified low cost catalytic bead type detector which has 3-wire 4-20mA or mV bridge output.
The diagram below illustrates how to determine which gas detector best suits the requirements of the end user.
*3/4 ” cable entry only available on aluminium junction boxes.
Visit hazardous area gas detectors for explosion and flameproof gas monitoring and detection instruments with certification for potentially explosive atmospheres, including Zone 1 and Zone 2 (according to ATEX and IECEx) and Class/Division categories (according to North American standards).
| Category | Gas Detection |
|---|
| Size | 156 x 166 x 111mm (6.1 x 6.5 x 4.3 inches) |
| Weight | 1kg (2.2lbs) |
| Enclosure material | Aluminium |
| Ingress protection | IP65 |
| Cable entries | 1 x M20, 1/2 “NPT or 3/4 NPT* on right-side |
| Terminations | 0.5 to 2.5mm2 |
| Sensor type | Catalytic bead |
| Operating temperature | mV: -40 to +80°C (-40 to 176°F) mA: -40 to +55°C (-40 to 131°F) |
| Storage | -25°C to +65°C (-13°F to +149°F) |
| Humidity | 10 to 95% RH |
| Repeatability Zero drift | <2% FSD (Typical) <2% FSD per Month (Typical) |
| Response time | T90 <15s (Typical) |
| Operating voltage | mA: 10-30V dc mV: 2.0V dc |
| Power requirements | mA: 50mA at 24V dc 1.2W mV: 300mA (Typical) |
| Electrical output | mA: 3- wire 4-20mA (current sink or source) mV: 3- wire mV bridge Typical signal: 12-15mV/ %LEL CH4 |
| Approvals | Not certified for use in hazardous environments |
| EMC compliance | EN 50270 FCC Part 15 ICES- 003 |
