Product Overview

Flameproof LED Escape Lighting – Appleton DEMULED

Zone 1 & Zone 2

Appleton ATX DEMULEDE042A

Zone 1 & Zone 2 (Gas) | Zone 21 & Zone 22 (Dust) Hazardous Areas

The DEMULED Series of Flameproof LED Escape Lights, manufactured by Appleton ATX, provide lighting for access on exit routes in hazardous environments during an evacuation. They are suitable for installation in hazardous areas designated as Zone 1, Zone 2, Zone 21 and Zone 22.

The ATEX certified flameproof LED escape lights are suitable for use indoor or outdoors where protection against dirt, water and moisture is essential. Typical applications include oil refineries, petrochemical facilities and pulp and paper mills.

• Product: Flameproof LED Escape Light
• Light Fitting Type: Linear Light Fitting
• Manufacturer: Appleton ATX
• Range: DEMULED
• Lamp Type: LED
• Lumen Output: 45 lumens
• Efficacy: 110 lm/w
• Voltage: 230 Vac, 50 Hz
• LED Lumen Depreciation (L70): 60,000+ hours
• Ambient Temperature: -30 °C to +55 °C (-22 °F to +131 °F)
• Battery optimum operating temperature: -5 °C to +30 °C (-22 °F to +131 °F)
• Emergency Duration: 1 Hour
• Surface Temperature: +75 °C (167 °F)
• Color Temperature: 5650K
• Color Rendering Index (CRI): 70+
• Cable Entries: M20
• Option: Adressable
• Flameproof LED Escape Light Weight: 7.8 kg | 17.2 lbs
• Flameproof LED Escape Light Volume: 36 dm³ | 2196.9 in³
• Replaceable Components: Driver and Battery
• ATX DEMULEDE042A is ideal for use in Zone 1 and Zone 21 as well as Zone 2 and Zone 22 hazardous area locations
• Hazardous Area Certified: ATEX & IECEx
• Light Fittings ATEX Zone 1 | Light Fittings ATEX Zone 2

Ordering LED Light Fittings

The following Appleton ATX part number generator explains the process for selecting the correct LED light fitting for Zone 1 & Zone 2 hazardous area lighting applications using the DEMULED range of flameproof LED escape lights.

ATEX & IECE x Hazardous Area Certifications and Compliances

• Certification Type: Appleton ATX DEMULED – Flameproof LED Escape Lights
— Gas: Zone 1 and 2 Hazardous Areas:
– Conforming to ATEX 94/9/CE: II 2 G
– Type of Explosion Protection: Ex d IIC
– Temperature Class: T6
— Dust: Zone 21 and 22 Hazardous Areas:
– Conforming to ATEX 94/9/CE: II 2 D
– Type of Explosion Protection: Ex tb IIIC
– Surface Temperature: +75 °C (167 °F)
• Ambient Temperature: -30 °C to +55 °C (-22 °F to +131 °F) 
• CE Declaration of Conformity: 50314
• ATEX Certificate: INERIS 15ATEX0056X
• IECEx Certificate: IECEx INE 15.0052X
• Index of Protection according EN/IEC 60529: IP66/68 (10m/1h)
• Impact Resistance (shock): IK09
• Internal Volume: > 2 dm3 (122 in³) – 2 liters
• Conforming to NF AEAS
