Andel Floodline Groundhog Mk II Panel single zone leak detection system that can be simply connected to any control or BMS system that has the capacity to accept volt-free contacts.
Andel Floodline Groundhog Mk II Panel single zone leak detection system that can be simply connected to any control or BMS system that has the capacity to accept volt-free contacts.
The single zone leak detection system is self contained and has flexible mounting options.
Contact our team to discuss how leak detection control panels, sensors and cables can secure BREEAM credits for sustainable building ratings.
Function: Water/Liquid detection
Zone: Single Zone (capacity 1)
Power Supply: Multi-voltage operation 12 or 24V AC or DC at 0.8watts
Control Panel Dimensions: L130 x W90 x D37 mm
Monitoring: LEAK – continuous water/liquid built-in sensor and aux sensor input, SYSTEM FAULT – aux sensor or Leader Cable
damage, failure or disconnection
Alarm Indicators: Flashing LEDs for LEAK and SYSTEM FAULT
All alarms displayed separately and continuously until corrected and reset if in manual mode
Outputs:
Leak/system fault – SPCO Relay 1Amp@24Vdc
Read our Blog to understand how the specification and installation of BREEAM Wat 03 Leak Detection Systems can help achieve BREEAM credits.
| Brand | Andel |
|---|---|
| Category | Mechanical |
Tell us your quantity and requirements — we reply within one business day.
Water Leak Detection – BREEAM Wat 03 Major Leak Detection SystemsAndel Single Zone water leak detection cables provide a solution for highly sensitive applications. The Single Zone Tape is a very strong, easy to install sensor.
Water Leak Detection – BREEAM Wat 03 Major Leak Detection SystemsAndel 4 Zone water leak detection is a highly absorbent detection cable that has for 10 years been in applications where maximum leak detection sensitivity is essential.
Water Leak Detection – BREEAM Wat 03 Major Leak Detection SystemsAndel 8 Zone water leak detection is a uniquely designed water sensitive cable that is able to have up to 8 reporting detection zones from just one length of cable (5 to…
