Andel Floodline Leak 1 Mk II Panel single zone leak detection system can be simply connected to any control or BMS system and is suitable for use with all floodline sensors.
Andel Floodline Leak 1 Mk II Panel single zone leak detection system can be simply connected to any control or BMS system and is suitable for use with all floodline sensors.
The compact module is din-rail mounted and screw terminals provide connections for the leak sensors, power input and volt-free contact output.
Contact our team to discuss how leak detection control panels, sensors and cables can secure BREEAM credits for sustainable building ratings.
Function: Water/Liquid detection
Zone: Single Zone (capacity 1)
Power Supply: Multi-Voltage 12 or 24v, AC or DC
Dimensions: Length 100mm, width 75mm, depth 22.5mm
Monitoring: LEAK – continuous water/liquid built-in sensor, SYSTEM FAULT – sensor or leader cable damage, failure or disconnection
Alarm Indicators: Flashing LEDs for LEAK or SYSTEM FAULT
All alarms displayed separately and continuously until corrected and reset if in manual mode
Outputs:
Leak/system fault – SPCO Relay 1Amp@24Vdc
Read our Blog to understand how the specification and installation of BREEAM Wat 03 Leak Detection Systems can help achieve BREEAM credits.
| Brand | Andel |
|---|---|
| Category | Mechanical |
