VEGABAR 83 Process Pressure Measurement Transmitter (Liquid & Gas)

Product Overview

Pressure Transmitter VEGA VEGABAR 83

Pressure Measurement for Liquids & Gases

VEGA VEGABAR 83 process pressure measurement transmitter with metallic measuring cell can be used to measure liquids and gases at high pressures.

VEGABAR 83 offers special advantages in applications with high pressures as a result of its metallic measuring cell offering high accuracy even under a vacuum and features:

• Maximum dependability and safety through proven technology
• High reliability through vacuum resistant version
• Universal use due to welded measuring cell

The pressure transmitter is ideal for level and pressure measurement of liquids and viscous products with high process pressure in all areas of industry and applications including:

• Gas scrubber
• Turbine steam line
• Raw milk tank
• Ice cream “Premix” mixer
• Jam cooking kettle
• Dissolution of waste paper and cellulose in the pulper

VEGABAR 83 Hazardous Area Certifications

VEGABAR 83 process pressure measurement transmitter is available with hazardous area certifications to meet ATEX & IECEX directives for Zone 1 and Zone 2 installations.

ATEX & IECEx Approvals

ATEX II 1G, 1/2G, 2G Ex ia IIC T6

ATEX II 1G, 1/2G, 2G Ex ia IIC T6 + Ship approval

ATEX II 1/2G, 2G Ex d IIC T6

IEC Ex ia IIC T6

VEGA process pressure measurement transmitters are suitable for use in hazardous areas and their instruments also have various ship approvals e.g according to GL, LRS or ABS.

Measuring Cell Technology

The main part of the pressure transmitter is the ceramic measuring cell that cleverly transforms the pressure into an electrical signal.

The pressure dependent signal is changed by the integrated electronics into a standard signal output. The sensor element METEC® is used with temperature ranges up to 200 °C and larger process fittings. This element consists of the ceramic-capacitive CERTEC® measuring cell and a special, temperature-compensated chemical seal system.

Material Transmitter

Available in 316Ti or Alloy C4 (2.4610), the process diaphragm of 316Ti or Elgiloy (2.4711). The process seal is available in FKM, FFKM, EPDM and NBR.

Housing Versions

The pressure transmitters housing available in single chamber version in plastic, aluminium and stainless steel. Protection rating IP 68K and external electronics with IP 69K.

Measuring Range

-1 … +1000 bar/-0.1 … +100 MPa (-14.5 … +15000 psig)

Smallest Measuring Range

+0.1 bar/+10 kPa (+1.45 psig)

Process Temperature

-40 … +200 °C (-40 … +392 °F)

Signal Output

• 4-20 mA
• 4-20 mA/HART
• Profibus PA
• Foundation Fieldbus

Approvals

• ATEX
• IEC
• FM
• EAC (GOST)
• Ship
• Overfill protection
• SIL2

VEGA VEGABAR pressure measurement transmitters to suit all liquid, gas, and vapour application with measuring distance (metres), pressure range (bar), temperatures (° Celsius) and process pressure.

Pressure Transmitter Applications

♦ Hydraulic Feed Pumps & Product Pipeline Pressure Monitoring – VEGABAR 83 provides reliable measurement of hydraulic pumps and feed pressures of product pipelines. Benefits:

• up to +1,000 bar
• Insensitive to shock or vibrations
• front-flush diaphragm

♦ Bitumen Tank Level Measurement – VEGABAR 83 can reliably provide level measurement even though the bitumen is kept at temperatures between +150 °C and +200 °C in asphalt mixing systems Benefits:

• available in flange and thread versions
• temperatures up to 200 °C
• diaphragm made of alloy C276 which is highly resistant
• metallic METEC® measuring cell with self-compensating temperature characteristics

♦ LNG Gas Pressure Measurement – VEGABAR 83 provides continuous pressure monitoring in LNG tanks where temperatures are as low as -163 °C and pressures are +250 mbar. Benefits:

• resistance to condensed moisture
• elastomer-free process fitting
• accessories available including shut off valves

♦ Level Measurement Of Milk In Dairies – VEGABAR 83 measures the level of milk stored in storage tanks in arduous conditions (during the cleaning cycle) at a temperature of +4 °C Benefits:

• CIP and SIP capable process fittings (suitab,e for food industry)
• resistance to condensed moisture
• excellent temperature shock reaction
