Zone 1 Zone 2 (21/22) Lighting – Hazardous Area Fluorescent Luminaires ATEX – Appleton RE

Appleton RE is part of the Zone 1 and Zone 2 (21/22) hazardous area fluorescent luminaire ATEX lighting range and are designed for flush or surface mounting, ideal for clean room environments…

CategoryATEX Lighting (Zone 1 & Zone 2)

Request Datasheet

Quoted to your quantity
Documentation on request
International delivery

Product Overview

Appleton RE is part of the Zone 1 and Zone 2 (21/22) hazardous area fluorescent luminaire ATEX lighting range and are designed for flush or surface mounting, ideal for clean room environments where a seamless, smooth ceiling is mandatory.

Typical applications of ATEX certified fluorescent luminaires include include the food industry, chemical plants, pharmaceuticals and delicate electronic manufacturing such as the aerospace industry. It is also ideal for use in rigorous corrosive environments, involving water, dust and extreme temperature variations.

Features & Benefits

One piece welded steel housing with integral frame to seal out contaminants.
Allows recessed mounting in permanent ceilings from 55 mm to 130 mm (2.17 to 5.12 in).
Frameless tempered 5 mm (1/4 in) thick lens. Lens secured to housing by internal metallic hinges and secured with captive 316L stainless steel screws, allowing for easy lamp replacement and fixture maintenance.
Positive safety switch and Ex e battery with plug-in connector for safety and easy maintenance in hazardous locations.
Designed for ease of lighting installation and maintenance.
Bi-pin G13 lampholder.
Also available as luminaire surface mounting version.
New ballast:
- — EOL (End Of Life) protection in accordance to the latest EN 60079-7 standard
- Multi-tap 110 to 254 Vac/Vdc +/-10% 50/60 Hz
- Two channel standard ballast (if one lamp fails the second lamp remains in operation)
- Ex e plug-in connector for rapid and error free maintenance
- Self test on 3 hours duration emergency version
- High power factor electronic ballast (>0.95)
- Cable entries:
  - Three clearance holes for M20 cable gland supplied with M20 polyamide cable gland — cable diameter 6.5 to 14.5 mm (0.26 to 0.57 in) — and M20 polyamide blanking plug. See Standard Cable Entry Accessories on following pages.
  - One M6 earth stud.

ATEX/IECEx Certifications for hazardous areas

ATEX/IECEx:
— Zone 1 and 2 – 21 and 22
— II 2 GD
— IP66

Technical Specifications

Category	ATEX Lighting (Zone 1 & Zone 2)

Recessed — 110/254 Vac/Vdc 50/60 Hz — Front access — White Painted Steel Housing
Standard Version — Bi-pin Lamps (G13)
Version	Wiring	Reflector	Weight (kg)	Volume (dm³)	Appleton Catalog Number
2 x 18W	Loop	Polycarbonate	14	64	REB218BUFL
2 x 18W	Through	Polycarbonate	14	64	REB218BUFT
4 x 18W	Loop	White Painted Steel	21	93	REB418BUFLP
4 x 18W	Through	White Painted Steel	21	93	REB418BUFTP
2 x 36W	Loop	Polycarbonate	19	108	REB236BUFL
2 x 36W	Through	Polycarbonate	19	108	REB236BUFT
4 x 36W	Loop	White Painted Steel	29	158	REB436BUFLP
4 x 36W	Through	White Painted Steel	29	158	REB436BUFTP
2 x 58W	Loop	Polycarbonate	22	130	REB258BUFL
2 x 58W	Through	Polycarbonate	22	130	REB258BUFT
4 x 58W	Loop	White Painted Steel	32	190	REB458BUFLP
4 x 58W	Through	White Painted Steel	32	190	REB458BUFTP
3 Hours Emergency Version — Bi-pin Lamps (G13)
Version	Wiring	Reflector	Weight (kg)	Volume (dm³)	Appleton Catalog Number
2 x 18W	Loop	Polycarbonate	14	64	REB218BUFLEP
2 x 18W	Through	Polycarbonate	14	64	REB218BUFTEP
4 x 18W	Loop	White Painted Steel	21	93	REB418BUFLEP
4 x 18W	Through	White Painted Steel	21	93	REB418BUFTEP
2 x 36W	Loop	Polycarbonate	19	108	REB236BUFLE
2 x 36W	Through	Polycarbonate	19	108	REB236BUFTE
4 x 36W	Loop	White Painted Steel	29	158	REB436BUFLEP
4 x 36W	Through	White Painted Steel	29	158	REB436BUFTEP
2 x 58W	Loop	Polycarbonate	22	130	REB258BUFLE
2 x 58W	Through	Polycarbonate	22	130	REB258BUFTE
4 x 58W	Loop	White Painted Steel	32	190	REB458BUFLEP
4 x 58W	Through	White Painted Steel	32	190	REB458BUFTEP
For non-recessed lighting, please replace letter “F” with letter “M” as per Catalog number logic. Example: REB218BUFL becomes REB218BUML.
