Zone 2 LED Streetlight Hazardous Area ATEX – Abtech STR1
The Abtech STR-1 is an ATEX certified Zone 2 LED street light designed for use in Zone 2 Gas and Zone 21 Dust environments. The Zone 2 LED streetlight is an LED…
CategoryATEX Lighting (Zone 1 & Zone 2)
- Quoted to your quantity
- Documentation on request
- International delivery
Product Overview
The Abtech STR-1 is an ATEX certified Zone 2 LED street light designed for use in Zone 2 Gas and Zone 21 Dust environments. The Zone 2 LED streetlight is an LED luminaire with excellent horizontal distribution. The LED light source provides an energy efficient, crisp white light. When combined with an appropriate lens from the range of options, the STR-1 streetlight is flexible enough for almost all hazardous area roadway and perimeter lighting applications.
Abtech LX2STR5LB41 manufactured from marine grade Aluminium, the Abtech STR-1 is designed to withstand the extreme climatic and corrosive conditions associated with Zone 2 hazardous area operation. The LED streetlight’s control gear has also been developed for heavy industrial use and features built in harmonic and overvoltage protection.
Features
- Part Number: LX2STR5LB41
- Low windage design suitable for mounting on poles 7-10m
- High performance optical design for maximum spacing between poles
- Maintenance free LED design with five-year complete system warranty
Hazardous Area Certification
Abtech STR1 LED streetlights are certified according to leading hazardous area classifications including:
- Area Classification Zone 2 & 22, Gas and Dust
- Type of Protection Ex nR (restricted breathing)
- Apparatus Coding Ex nR IIC T* Gc, Ex tc IIIC T100ºC Dc
- Certificate Number AB15ATEX4111X
Technical Specifications
| Category | ATEX Lighting (Zone 1 & Zone 2) |
|---|
| Luminaire Type | Zone 2 LED road lantern |
| Ingress Protection | IP66 to EN60529 |
| Material | Epoxy painted die cast marine grade Aluminium body, toughened glass window, silicone gasket and stainless steel fixings |
| Distribution/output | ERS standard road luminance optic |
| Lamp Types | Light emitting diode (4100K) |
| LED Life | 60,000 hours L80 @ 50°C |
| Colour Rendering Index | >75 |
| Cable Entry | 1 x M20 clearance hole |
| Terminals | Terminals block for up to 4mm2 conductors |
| Control Gear | HF electronic driver with overvoltage and harmonic protection to EN61000-3-2, EN 61000- 3-3 and EN 61000-4-5 |
| Orientation | Horizontal, beam down |
| Mounting | Side arm mounting – Ø60 to Ø62mm |
| Supply | 90 to 305V 50/60Hz ac |
| Abtech Product Reference | LampType | Lumen Output (lm) | Power (W) | Windage (m2) | Ambient Temperature | Weight (kg) |
| LX2STR5LB41 | LED | 12,348 | 120 | 0.07 | – 50°C to +55°C | 11Kg |
