Type P Control Cable Unarmoured

These cables are intended for use as control cables aboard ship and on off-shore oil rings. The cables are constructed in accordance with the recommended practice for marine cable for…

Rated voltage600/1000 V
ConductorSoft annealed flexible stranded tinned copper wire acc. to IEEE 1580 Table 11
InsulationCross-linked polyolefin compound, in accordance with Type P of IEEE 1580 and Type X110 of UL 1309/CSA C22.2 No.245.
SheathThermoset chlorinated polyethylene, CPE compound, in accordance with IEEE 1580 and UL 1309/CSA C22.2 No.245
Request a Quote
Request Datasheet
  • Quoted to your quantity
  • Documentation on request
  • International delivery

Product Overview

These cables are intended for use as control cables aboard ship and on off-shore oil rings. The cables are constructed in accordance with the recommended practice for marine cable for use on fixed or floating facilities, IEEE 1580. Excellent resistance to oil, abrasion petrochem fluids, moisture salty water and sunlight.

Technical Specifications

Rated voltage600/1000 V
ConductorSoft annealed flexible stranded tinned copper wire acc. to IEEE 1580 Table 11
InsulationCross-linked polyolefin compound, in accordance with Type P of IEEE 1580 and Type X110 of UL 1309/CSA C22.2 No.245.
SheathThermoset chlorinated polyethylene, CPE compound, in accordance with IEEE 1580 and UL 1309/CSA C22.2 No.245
SeparatorA suitable separator tape may be applied to the conductor (optional for manufacturer)
SeparatorA suitable separator tape may be applied (optional for manufacturer)
Reference standardsIEEE 1580, UL 1309, CSA C22.2 No.245, IEEE 45
Insulation materialIEEE 1580, UL 1309, CSA C22.2 No.245
Sheath materialIEEE 1580, UL 1309, CSA C22.2 No.245
Conductor materialASTM B 33
Conductor resistanceIEEE 1580 Table 11
Flame propagationIEEE 1202, IEC 60332-3
Cold bend (-40)CSA C22.2
Cold impact (-35)CSA C22.2
Temperature rating IEEE 1580100°C (Single Core 125°C)
Temperature rating UL 1309110°C (Single Core 125°C)
Test voltageIEEE 1580 Table 19
Min. bending radius6 x D
Current carrying capacityIEEE 45.8; MIN. BENDING RADIUS
For D≤25 mm4 x D
For D>25 mm6 x D
* canCable Article Number; * This can numbers for Black outer sheath

** Ambient air temperature at 45 °C

CAN*Cable TypeCross-SectionOuter Sheath DiameterApprox. Cable Weight (kg/km)Min. Bending Radius (mm)Current Carrying Capacity 100°C (**) (A)Current Carrying Capacity 110°C (**) (A)Max. Electrical Resistance at 20°C (ohm/km)
Min. (mm)Nom. (mm)Max. (mm)
6414.1C18PCPE-44×18 AWG9,09,911,012744121320,384
6414.4C18PCPE-88×18 AWG12,013,415,0239608920,384
6414.5C18PCPE-1010×18 AWG14,015,417,0298686720,384
6414.6C18PCPE-1212×18 AWG14,515,917,5324706720,384
6414.7C18PCPE-1616×18 AWG16,017,519,0409766720,384
6414.8C18PCPE-1919×18 AWG17,018,420,0462806720,384
6414.9C18PCPE-2020×18 AWG17,519,321,0502846720,384
6414.10C18PCPE-2424×18 AWG19,521,323,0587925620,384
6414.11C18PCPE-2727×18 AWG20,021,823,5635945620,384
6414.12C18PCPE-3737×18 AWG23,525,427,58721655520,384
6414.13C18PCPE-4444×18 AWG26,028,330,51.0601834520,384
6414.14C18PCPE-6060×18 AWG29,031,333,51.3392014520,384
6414.15C18PCPE-9191×18 AWG34,537,240,01.9262404420,384
6414.16C16PCPE-44×16 AWG9,410,311,514446161715,778
6414.17C16PCPE-55×16 AWG10,011,212,517350131415,778
6414.18C16PCPE-77×16 AWG11,012,113,521454111215,778
6414.19C16PCPE-88×16 AWG13,514,916,529666111215,778
6414.20C16PCPE-1010×16 AWG15,016,117,5338708915,778
6414.21C16PCPE-1212×16 AWG15,016,618,0370728915,778
6414.22C16PCPE-1616×16 AWG17,018,320,0469808915,778
6414.23C16PCPE-1919×16 AWG17,519,221,0532848915,778
6414.24C16PCPE-2020×16 AWG18,520,222,0577888915,778
6414.25C16PCPE-2424×16 AWG21,523,425,57231537815,778
6414.26C16PCPE-2727×16 AWG22,023,926,07811567815,778
6414.27C16PCPE-3737×16 AWG24,526,628,51.0061716715,778
6414.28C16PCPE-4444×16 AWG27,529,732,01.2231926615,778
6414.29C16PCPE-6060×16 AWG30,532,835,01.5532106615,778
6414.30C16PCPE-9191×16 AWG36,539,042,02.2432525515,778
6414.31C14PCPE-44×14 AWG10,011,212,51855025279,996
6414.32C14PCPE-55×14 AWG11,012,213,52235420229,996
6414.33C14PCPE-77×14 AWG12,013,214,52815818199,996
6414.34C14PCPE-88×14 AWG15,016,218,03817218199,996
6414.35C14PCPE-1010×14 AWG16,017,619,04397613149,996
6414.36C14PCPE-1212×14 AWG16,518,120,04848013149,996
6414.37C14PCPE-1616×14 AWG18,520,022,06188813149,996
6414.38C14PCPE-1919×14 AWG19,521,123,07059213149,996
6414.39C14PCPE-2020×14 AWG21,523,225,081115013149,996
6414.40C14PCPE-2424×14 AWG24,025,727,594916511129,996
6414.41C14PCPE-2727×14 AWG24,526,228,51.03017111129,996
6414.42C14PCPE-3737×14 AWG27,029,231,51.33818910119,996
6414.43C14PCPE-4444×14 AWG30,532,635,01.627210999,996
6414.44C14PCPE-6060×14 AWG33,536,138,52.085231999,996
6414.45C14PCPE-9191×14 AWG40,543,146,03.034276889,996
6414.46C12PCPE-44×12 AWG11,512,313,52465431336,292
6414.47C12PCPE-55×12 AWG12,513,415,03006025266,292
6414.48C12PCPE-77×12 AWG14,015,517,04056822236,292
6414.49C12PCPE-88×12 AWG16,517,919,55097822236,292
6414.50C12PCPE-1010×12 AWG18,019,521,05898416176,292
6414.51C12PCPE-1212×12 AWG18,520,122,06568816176,292
6414.52C12PCPE-1616×12 AWG21,523,325,589015316176,292
6414.53C12PCPE-1919×12 AWG22,524,526,51.01615916176,292
6414.54C12PCPE-2020×12 AWG24,025,728,01.09816816176,292
6414.55C12PCPE-2424×12 AWG26,528,530,51.29018314156,292
6414.56C12PCPE-2727×12 AWG27,029,131,51.40718914156,292
6414.57C12PCPE-3737×12 AWG30,532,435,01.84221012136,292
6414.58C12PCPE-4444×12 AWG34,036,439,02.23823411126,292
6414.59C12PCPE-6060×12 AWG38,040,443,02.89125811126,292
6414.60C12PCPE-9191×12 AWG46,549,853,04.3773189106,292

Features

  • Flame retardant

Certifications / Standards

  • UL
